16,000 ANSI / 18,000 ISO Lumens | Contrast Ratio: 10,000:1 (Dynamic Black) | Part Number: 120-605
Colour System: |
DMD Specification:
|
Blue Laser Phosphor + 4-segment colour wheel
Display Type:
|
1 x 0.96" DarkChip™ DMD™ |
|
1920 x 1200 pixels native display.
Fast transit pixels for smooth greyscale and improved contrast.
Aspect Ratio:
16x10
Fill Factor
87% |
Key Features
Video & Graphics Processing
- HDMI 1.4b for Side by Side, Frame Packing, Frame Sequential & TopBottom 3D Formats.
- Dual Flash Processing can be used to multiply the displayed frame rate for 3D sources.
- Dual Pipe Processing: Two sources in parallel for Left and Right eyes.
- Synchronisation of active glasses.
- 3G-SDI with loop-through.
- 24p and 1080p native display.
Geometry Correction
- Cornerstone, Vertical & Horizontal Keystone, Pincushion & Barrel, and Image Rotation.
- Blanking control for custom input window sizing.
- Scaling for fixed aspect ratio screens.
Edge Blending
- Correction for non-active pixels at the edge of the display.
Picture in Picture
- Two sources can be displayed either one within the other (PIP) , or side by side, with the original aspect ratios maintained.
HDBaseT® Interface
- Built in support for transmission of uncompressed High Definition Video over standard CAT5e/6 LAN cable.
- Allows the projector to be placed up to 100m from source with low cost cabling.
Colour Processing
- Powerful seven-point colour correction for accurate colour matching.
Projector Controller Software
- Intuitive user interface for network control.
- Simultaneous control of user-defined groups of projectors.
- At-a-glance monitoring of projector status.
Projector Automation
- Real-time clock provides daily on/off automation.
Installation
- Integrated stacking mount pins.
- Eye bolts included for easy rigging.
|
Source Compatibility:
|
3GSDI is SMPTE 292M, SMPTE 259M-C and SMPTE 424M compliant.
HDMI including Deep Color™ processing.
Graphics standards up to 1920 x 1200 resolution at 60Hz via HDMI or DisplayPort. |
Inputs/Outputs
Video & Computer |
Type |
Connector |
Qty |
DisplayPort 1.1a
HDMI 1.4a
3G-SDI in
3G-SDI out
HDBaseT (see LAN) |
DisplayPort
HDMI
BNC
BNC
LAN RJ45 |
2
2
1
1
1 |
Communication & Control |
Type |
Connector |
Qty |
3D Sync Out
3D Sync In
LAN
RS232
Wired Remote
12V Trigger
NOTE: The HDBaseT and LAN ports are not shared. |
BNC
BNC
RJ45
9-pin D-Sub
3.5mm Stereo Jack
3.5mm Stereo Jack |
1
1
1
1
1
2 |
3D Formats Supported
|
HDTV Formats Supported
|
Frame Packing Dual Pipe Frame Sequential Side By Side (half) Top and Bottom |
1080p (24Hz, 25Hz, 30Hz, 50Hz, 60Hz), 1080i (50Hz, 60Hz), 720p (50Hz, 60Hz) |
Computer Compatibility |
Bandwidth |
Up to 1920 x 1200 |
165 MHz on analog RGB
165 Megapixels per second on HDMI |
Remote Control |
Automation Control |
Addressable IR Remote Control, wireless and wired
On-Board keypad |
Crestron RoomView® Connected PJLink Class 1 LAN RS232 AMX (Device Discovery) Served web page |
Colour Temperature |
Operation |
3200K to 9300K |
 |
illumination Type
|
Typical illumination Life
|
Laser Light Source |
20,000 hours |
Lenses |
Lens |
Part No. |
Optimised Focus Range*
|
Lens Shift |
0.9 - 1.2 : 1 zoom |
120-624 |
0.92m - 13.46m |
Vert: 0.45 (U) 0.45 (D) frame, Hor: 0.15 (L) 0.15 (R) frame |
1.20 - 1.56 : 1 zoom |
120-625 |
1m - 17.5m |
Vert: 0.5 (U) 0.5 (D) frame, Hor: 0.15 (L) 0.15 (R) frame |
1.50 - 2.00 : 1 zoom |
120-626 |
2m - 21.8m |
Vert: 0.5 (U) 0.3 (D) frame, Hor: 0.15 (L) 0.15 (R) frame |
2.00 - 4.00 : 1 zoom |
120-627 |
2.5m - 41.8m |
Vert: 0.5 (U) 0.3 (D) frame, Hor: 0.15 (L) 0.15 (R) frame |
4.00 - 7.00 : 1 zoom |
120-628 |
4m - 42m |
Vert: 0.5 (U) 0.3 (D) frame, Hor: 0.15 (L) 0.15 (R) frame |
* Lens focal ranges above are the optimised distances but are likely to focus further, please contact your RSM for more details. Lens ratio tolerances: E-Vision Series: +/-3%. HighLite Series: +/- 5%. M-Vision Series: +/- 2%. Titan Series: +/-2%, INSIGHT Series: +/-2%,
Lens Mount |
Motorised shift, zoom and focus, with programmable shift |
Mechanical Mounting |
Orientation |
Front/Rear Table
Front/Rear Ceiling
Adjustable Front/Rear Feet |
Table Top or Inverted: Yes
Pointing Up: Yes
Pointing Down: Yes
Roll (Portrait): Yes |
Power Requirements |
Power Consumption |
100 - 240VAC 50/60Hz single phase * Note that in 120V operation, the projector will be at 65% brightness |
Typical 2000W @ 240VAC in Normal mode
Typical 1200W @ 240VAC in ECO mode
Typical 1200W @ 110VAC in Normal mode
Typical 1000W @ 110VAC in ECO mode |
Thermal Dissipation
|
Fan Noise
|
Typical 6482 BTU/Hour @ 220VAC in Normal mode
Typical 3753 BTU/Hour @ 110VAC in Normal mode |
Normal mode: 45 dBA max, 42 dBA typical
Eco mode: 42 dBA max, 39dBA typical
|
Operating/Storage Temperature
|
Operating Humidity
|
Operating: 0 to 40C (32 to 104F)
Storage: -20 to 60C (-4 to 140F) |
10% to 90% relative, non-condensing |
Weight (Chassis Only)
|
Dimensions
|
49 kg
108 lb
|
H: 24.8 cm W: 53.0 cm L: 69.5 cm
H: 9.8 in W: 20.9 in L: 27.4 in |
Safety & EMC Regulations
|
|
UL/cUL, CB, CCC, FCC Class A , CE, RoHS 2
IEC EN 60825-1:2014 Class 1 Laser Product
IEC 60825-1:2007 Class 3R Laser Product
IEC EN 62471-5:2015 Risk Group 3 |
|
Accessories |
Accessory |
Part No. |
Infrared Remote (replacement)
|
117-780 |
*Dimensions included for reference only and are subject to change. Please download the full set of CAD files for this display for more accurate information.
Specifications subject to change without notice. ©2020 Digital Projection.
