| Colour System: |
Laser Phosphor with ColorBoost+Red Laser |
| Display Type: |
3 x 0.96" WUXGA DMD™
|
| DMD Specification: |
Display capability up to WUXGA
Fast transit pixels for smooth greyscale and improved contrast.
|
| Aspect Ratio: |
16:10 |
| Fill Factor |
87% |
| Key Features: |
Video & Graphics Processing
- HDMI 2.0 compliance for Side by Side, Frame Packing, Frame Sequential and TopBottom 3D Formats.
- DisplayPort 1.2 with HDCP 2.2 compliance.
- 10-bit colour processing (30-bits per pixel).
- Support for 1080p 24Hz native display.
- Support for 4K 4096 x 2160 resolution. Output will be scaled to WUXGA
- HDR support
- Input source automatically detected.
- Input redundancy mode with auto switching.
- Dual Pipe Processing: Two sources in parallel for Left and Right eyes.
- Syncronisation of active 3D glasses or polarising switcher.
- DICOM simulation mode.
- Sealed light engine
General Features
- Constant Brightness control
- Multi Projector brightness and colour control.
- Compatible with selected 3rd party lenses via lens converter
- Selectable EDID
- Custom Start-up Logo
- Smear Reduction (fast frame) (2D Only)
- Electronic PIC MUTE with selectable fade in/out timers
- On board 4 -line LCD display for at a glance status
Geometry Correction
- Vertical & Horizontal Keystone correction.
- Four Corner adjustment.
- Rotation.
- Pin/Barrel.
- Wall Corner adjustment.
- Centre Shift (Horizontal and Vertical linearity adjustment).
- Custom Warp.
- Upload of maps for warp, blend, uniformity and masking.
- Selectable aspect ratios: 5:4 / 4:3 / 16:10 /16:9 / 1.88 / 2.35 / TheaterScope / Source / Unscaled.
- Digital Zoom.
- Blanking control for custom input window sizing.
Edge Blending
- Blending control available for all sides with width control.
- Correction for non-active pixels at the edge of the display.
- Electronic Black Level Compensation.
- Upload of Blend Maps including Blend, Uniformity, Masking, Pixel by Pixel
HDBaseT® Interface
- Built in support for reception of uncompressed High Definition Video over standard CAT5e/6 LAN cable
- Allows projector to be placed up to 100m from source with low cost cabling
- Supports up to 4K 4096 x 2160@60Hz 4:2:0 or 4K 4096 x 2160@30Hz 4:2:2
- Includes Ethernet 100BaseT and RS232/IR control.
Colour Processing
- Four colour modes available
- Powerful seven point colour correction for accurate colour matching with presets.
- Easy colour temperature selection
- Manual seven point colour adjustment
- Traditional lifts and gains
Projector Controller Software
- Intuitive user interface for network control
- Simultaneous control of user-defined groups of projectors
- At-a-glance monitoring of projector status
Projector Automation
- Real-time clock provides daily on/off automation
- E-mail alerts for system status
Installation
- 4 x eye bolts fitted for easy rigging.
- 4 x top stacking mounts and mount securing pins supplied as standard accessories.
|
| Source Compatibility |
2D Graphics standards up to 4K-UHD 3840x2160 resolution at 60Hz via HDMI 2.0b, HDBaseT (4:2:0), DisplayPort inputs
3D Graphics standards up to dual-pipe WUXGA 60Hz for input (120Hz output) via HDMI 2.0 and Display Port inputs
12G-SDI is SMPTE 259M, 292M, 424M and ST-2082 compliant.
WUXGA mode
2D sources up to WUXGA 60Hz and 4K-UHD 60Hz can be displayed scaled to fit WUXGA
3D sources up to WUXGA 60Hz Input -120Hz output can be displayed scaled to fit WUXGA
Auto Mode
Sources greater than WUXGA will be displayed scaled to fit WUXGA
|
| Inputs/Outputs |
| Video & Computer |
| Type |
Connector |
Qty |
DisplayPort 1.2a (2D)
HDMI 2.0b
12G-SDI in
12G-SDI out
HDBaseT/LAN |
DisplayPort
HDMI
BNC
BNC
RJ45 |
2
2
1
1
1 |
.
| Communication & Control |
| Type |
Connector |
Qty |
3D SYNC IN
3D Sync Out
LAN
RS-232
Wired Remote
12V Trigger
3D Sync IR Out
USB 5V 2A |
BNC
BNC
RJ45
9-pin D-Sub
3.5mm Stereo Jack
3.5mm Stereo Jack
BNC
Type A |
1
1
1
1
1
1
1
1 |
|
| 3D Formats Supported |
Sequential / 1080p @100Hz
Sequential / 1080p @120Hz
Dual-Pipe / 1080p @ 50Hz per eye
Dual-Pipe / 1080p @ 60Hz per eye
Dual-Pipe / WUXGA @ 60Hz
Also supports mandatory formats including side by side, top/bottom and frame packing
|
| HDTV Formats Supported |
1080p (23.98Hz, 24Hz, 25Hz, 29.97Hz, 30Hz, 50Hz, 59.94Hz, 60Hz).
1080i (50Hz, 59.94Hz, 60Hz).
720p (50Hz, 59.94Hz, 60Hz).
4K-UHD (23.97Hz, 24Hz, 25Hz, 29.97Hz, 30Hz, 50Hz, 60Hz) (Output will be sclaed to WUXGA).
|
| Computer Compatibility |
2D
4K-UHD up to 60Hz (Output will be scaled to WUXGA)
3D
Supported Formats will be displayed up to WUXGA |
| Bandwidth |
18Gb/s (600MHz clock rate) on HDMI |
| Remote Control |
Addressable IR remote Control, Wireless and wired. On-Board keypad |
| Automation Control |
LAN
RS-232
Alert E-Mails from Projector
Served webpage OSD functions for full Projector Control via web browser
LAN Control-Crestron Roomview™
LAN Control-Crestron eControl
LAN Control-PJ Link compatible
LAN Control-AMX SSDP
LAN to RS232 (RS232 by Telnet)
Concurrence Control for RS232/LAN
DMX Art-Net control
Scheduled On and Off times |
| Colour Temperature |
3200K to 9300K |
| Operation |
 |
| illumination Type |
Laser Light Source |
| Typical illumination Life |
20,000 Hours (Normal Mode) 40,000 Hours (ECO Mode) |
| Lenses |
| Lens |
Part No. |
Optimised Focus Range* |
Lens Shift (Frame) |
| 0.37:1 (Right Angled) |
120-510 |
1.6m - 4.9m |
Vert: 0.6 (U) 0.6 (D) frame, Hor: 0.31 (L) 0.31 (R) frame |
| 0.65-0.85:1 (Right Angled) |
120-511 |
2.8m - 8.4m |
Vert: 0.51 (U) 0.51 (D) frame, Hor: 0.24 (L) 0.24 (R) frame |
| 0.8-1.16:1 (Includes support bracket) |
120-827 |
1.7m - 11m |
Vert: 0.4 (U) 0.4 (D) frame, Hor: 0.19 (L) 0.19 (R) frame |
| 0.67:1 fixed HB |
105-607 |
1.1m - 10m |
Vert: 0.108 (U) 0.108 (D) frame, Hor: 0.044 (L) 0.044 (R) frame |
| 1.12:1 (short) fixed HB |
105-608 |
3m - 15m |
Vert: 0.567 (U) 0.567 (D) frame, Hor: 0.273 (L) 0.273 (R) frame |
| 1.16 - 1.49:1 zoom HB |
109-236 |
3m - 15m |
Vert: 0.408 (U) 0.408 (D) frame, Hor: 0.188 (L) 0.188 (R) frame |
| 1.39 - 1.87:1 zoom HB |
105-610 |
4m - 24m |
Vert: 0.567 (U) 0.45 (D) frame, Hor: 0.273 (L) 0.273 (R) frame |
| 1.87 - 2.56:1 zoom HB |
105-611 |
4m - 24m |
Vert: 0.567 (U) 0.45 (D) frame, Hor: 0.273 (L) 0.273 (R) frame |
| 2.56 - 4.16:1 zoom HB |
105-612 |
9.1m - 45m |
Vert: 0.567 (U) 0.45 (D) frame, Hor: 0.273 (L) 0.273 (R) frame |
| 4.16 - 6.96:1 zoom HB |
105-613 |
12m - 80m |
Vert: 0.567 (U) 0.45 (D) frame, Hor: 0.273 (L) 0.273 (R) frame |
| 6.92 - 10.36:1 zoom HB |
109-235 |
12m - 80m |
Vert: 0.567 (U) 0.45 (D) frame, Hor: 0.273 (L) 0.273 (R) frame |
* Lens focal ranges above are the optimised distances but are likely to focus further, please contact your RSM for more details. Lens ratio tolerances: E-Vision Series: +/-3%. HighLite Series: +/- 5%. M-Vision Series: +/- 2%. Titan Series: +/-2%, INSIGHT Series: +/-2%,
|
| Lens Mount |
Motorised Shift, Zoom and Focus.
Intelligent Lens Memory with 10 user-definable pre-set positions for zoom lenses. |
| Mechanical Mounting |
Front/Rear Table
Front/Rear Ceiling
Adjustable Front/Rear Feet |
| Orientation |
Table Top or Inverted: Yes
Pointing Up: Yes
Pointing Down: Yes
Roll (Portrait): Yes |
| Power Requirements |
110V~130Vac/ 50~60Hz 180V~240Vac/ 50~60Hz single phase * Note that in 120V operation, the projector will be at ~25% brightness |
| Power Consumption |
230V Typical: 3650W , Maximum 4000W
|
| Thermal Dissipation |
Max 14160.38 BTU/hr @ 200VAC
Max 3685 BTU/hr @ 110VAC |
| Fan Noise |
Max 53 dBA Eco Typ : 50 dBA |
| Operating/Storage Temperature: |
Operating: Full Power 0°C ~ 35°C (32°F ~95°F), ECO upto 40°C (104°F)
Storage: -20°C ~ 60°C (-4°F ~ 140°F) |
| Operating Humidity |
Operating: 10% ~ 90% non-condensing
Storage: 10% ~ 90% non-condensing |
| Weight |
88 (without lens) kg / 194 (without lens) lbs |
| Dimensions |
L: 840mm, W: 650mm, H: 381mm (Excl handles)
L: 33.1in, W: 25.6in, H: 15in (Excl handles)
* See drawings for full details |
| Safety & EMC Regulations |
TBC |
| Accessories |
| Accessory |
Part No. |
Infrared Remote Control (Replacement)
|
118-678
|
*Dimensions included for reference only and are subject to change. Please download the full set of CAD files for this display for more accurate information.
|
