| Colour System: |
Laser Phosphor with Colorboost (Red Laser).
Phosphor wheel: 2 x 7200rpm (120Hz)
Colour wheel: 4 Segment RGBY 2 x 7200rpm (120Hz) |
| Display Type: |
1 x 0.8" HEP DMD™ (High Efficency Pixel)
|
| DMD Specification: |
1920 x 1200 pixels native display.
Fast transit pixels for smooth greyscale and improved contrast. |
| Aspect Ratio: |
16x10 |
| Fill Factor |
|
| Key Features: |
Video & Graphics Processing
- Nexus electronics platform
- HDMI 2.0
- DisplayPort 1.2
- 10-bit colour processing (30-bits per pixel) 1,073,741,824 colours
- Hue, Saturation and Gain colour management.
- 24p and 1080p native display.
- HDR support
- Input source automaticaly detected
- Selectable Dynamic Black
- Syncronisation of active glasses or polarising switcher.
- DICOM simulation mode
- Optics engine sealed to IP6X
Geometry Correction
- Vertical & Horizontal Keystone correction
- Four Corner adjustment
- Rotation -100 to +100 with +/- 0.25° per step
- Selectable aspect ratios: 5:4 / 4:3 / 16:10 /16:9 / 1.88 / 2.35 / TheaterScope / Source / Unscaled
- Digital Zoom 0% ~ 100%
- Blanking control for custom input window sizing.
- Scaling for fixed aspect ratio screens.16:10 / 16:9 / 4:3 / 2.35:1
- Custom warp
Edge Blending
- Correction for non-active pixels at the edge of the display.
HDBaseT® Interface
- Built in support for transmission of uncompressed High Definition Video over standard CAT5e/6 LAN cable.
- Allows the projector to be placed up to 100m from the source with low cost cabling.
- HDBaseT® Includes Ethernet 100BaseT and RS232/IR control.
Colour Processing
- Powerful seven point colour correction for accurate colour matching.
Projector LAN Control
- Free Digital Projection Projector Controller II software
- Intuitive user interface for network control.
- At-a-glance monitoring of projector status.
- Simultaneous control of user-defined groups of projectors.
|
| Source Compatibility |
Graphics standards up to WQXGA 2560 x 1600 60 Hz RB (DisplayPort).
Display Support for 3840 x 2160 (4K-UHD) up to 60Hz and 4096 x 2160 (4K) up to 60Hz. |
| Inputs/Outputs |
| Video & Computer |
| Type |
Connector |
Qty |
HDMI 2.0 (HDCP compatible)
DisplayPort 1.2
HDBaseT
3G-SDI in
3G-SDI out |
HDMI
DisplayPort
8P8C "RJ45"
BNC
BNC |
2
2
1
1
1 |
.
| Communication & Control |
| Type |
Connector |
Qty |
3D Sync In
3D Sync Out (loop through)
3D Sync Out for IR
LAN / Art-Net
HDBaseT/Ethernet/RS232/IR
Serial In RS-232C
Serial Out RS-232C
Wired Remote In
Wired Remote Out
12V Trigger 12V 350mA
USB Power out 5V/2A |
BNC
BNC
BNC
EtherCON RJ45
RJ45
9-pin D-Sub
9-pin D-Sub
3.5mm Stereo Jack
3.5mm Stereo Jack
3.5mm Stereo Jack
USB Type A |
1
1
1
1
1
1
1
1
1
1
1 |
|
| 3D Formats Supported |
Off
Auto
Side by Side
Top and Bottom
Dual Pipe
Frame Sequential
|
| HDTV Formats Supported |
EDTV (480p, 576p), HDTV (720p, 1080i, 1080p), Display Support for 3840 x 2160 (4K-UHD) up to 60Hz and 4096 x 2160 (4K) up to 60Hz |
| Computer Compatibility |
VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA up to 60hz RB, Mac |
| Bandwidth |
|
| Remote Control |
Infrared Remote Control Unit |
| Automation Control |
LAN - Webpage control
TCP/UDP control
RS-232
Alert Mail for Projector
LAN Control-Crestron® Connected
LAN Control-PJ Link Class 1 compatible
LAN Control-AMX® Device Discovery
Art-Net (DMX) control
|
| Colour Temperature |
User selectable (3200K/ 5400K / 6500K / 7500K / 9300K / Native ) |
| Operation |
 |
| illumination Type |
Laser Phosphor. ECO mode support (80% Brightness) |
| Typical illumination Life |
20,000 hours |
| Lenses |
| Lens |
Part No. |
Optimised Focus Range* |
Lens Shift (Frame) |
| 0.31 - 0.33:1 zoom |
124-318 |
0.38 - 3.01m |
Vert: +/- 50%
Hor: +/- 20% |
| 0.55 - 0.75:1 zoom |
124-319 |
0.69 - 6.58m |
Vert: +/- 50%
Hor: +/- 20% |
| 0.74 - 1.08:1 zoom |
124-320 |
0.75 - 12.19m |
Vert: +/- 50%
Hor: +/- 20% |
| 1.05 - 1.41:1 zoom |
124-321 |
1.06 - 18.94m |
Vert: +/- 60%
Hor: +/- 20% |
| 1.4 - 2.11:1 zoom |
124-322 |
1.47 - 27.86m |
Vert: +/- 60%
Hor: +/- 20% |
| 2.1 - 4.0:1 zoom |
124-323 |
2.24 - 54.19m |
Vert: +/- 60%
Hor: +/- 20% |
| 3.0 - 4.52:1 zoom |
112-503 |
2.53 - 47.2m |
Vert: +/- 45%
Hor: +/- 10% |
| 4.46-6.94:1 zoom |
112-504 |
3.71 - 76.7m |
Vert: +/- 45%
Hor: +/- 10% |
* Lens focal ranges above are the optimised distances but are likely to focus further, please contact your RSM for more details. Lens ratio tolerances: E-Vision Series: +/-3%. HighLite Series: +/- 5%. M-Vision Series: +/- 2%. Titan Series: +/-2%, INSIGHT Series: +/-2%,
|
| Lens Mount |
Centred lens for installation flexability
Motorised and programmable shift, zoom and focus.
Intelligent Lens Memory with 10 user-definable preset positions (except UST lens). |
| Mechanical Mounting |
Front/Rear Table
Front/Rear Ceiling
Adjustable Front/Rear Feet
Ceiling Mount compatible chassis with 6 off M4*0.7 mounting holes available, Maximum screw length 16mm |
| Orientation |
Table Top or Inverted: Yes
Pointing Up: Yes
Pointing Down: Yes
Roll (Portrait): Yes |
| Power Requirements |
110-240 VAC 11.0A 50/60Hz |
| Power Consumption |
at 110VAC - typical 1100 W, max 1200 W in Normal mode
at 110VAC - typical 900 W, max 1000 W in High Altitude mode
at 220VAC - typical 1300 W, max 1400 W in Normal mode
at 220VAC - typical 900 W, max 1000 W in Eco mode
at 220VAC - typical 900 W, max 1000 W in High Altitude mode |
| Thermal Dissipation |
at 110 VAC: typical 3576 BTU/hr, max 4097 BTU/hr in Normal mode
at 110 VAC: typical 3073 BTU/hr, max 3415 BTU/hr in High Altitude mode
at 220 VAC: typical 4438 BTU/hr, max 4780 BTU/hr in Normal mode
at 220 VAC: typical 3073 BTU/hr, max 3415 BTU/hr in ECO mode
at 220 VAC: typical 3073 BTU/hr, max 3415 BTU/hr in High Altitude mode |
| Fan Noise |
Typical 44dB, max 46dB in Normal mode
Typical 39dB, max 41dB in ECO mode |
| Operating/Storage Temperature: |
Operating: 0 to 40 °C (32 to 104 °F)
Force ECO over 35°C (95°°F) |
| Operating Humidity |
90% (with maximum temperature of 35°C (95°F) |
| Weight |
30kg (without lens) kg / 66.1lb (without lens) lbs |
| Dimensions |
L: 598mm x W: 500mm x H:218mm
L: 23.54 inch x W: 19.68 inch x H: 8.58 inch |
| Safety & EMC Regulations |
cTUVus, CB report, CCC (China), CECP (China Energy Conservation Program), China RoHS, FCC part 15 Class A, FDA 21 CFR part 1040 (Except with respect to those characteristics authorised by Variance Number 2021-V-0192, CE (European Economic Area), UKCA (United Kingdom), KC (Korea), BSMI (Taiwan), RCM (Australia),IEC 60825-1 : 2014 - Class 1 Laser Product, IEC EN 62471-5:2015 - Risk Group 2< br/>
This projector may become Risk Group 3 when an interchangeable lens with a throw ratio of greater than 2.12:1 is installed
Such combinations of projector and lens are intended for professional use only and are not intended for consumer use. |
| Accessories |
*Dimensions included for reference only and are subject to change. Please download the full set of CAD files for this display for more accurate information.
|
