| Colour System: |
Laser Phosphor & Red Laser |
| Display Type: |
3 x 0.96" WUXGA DMD™
|
| DMD Specification: |
Display capability up to 4K-UHD
8.3 megapixels on screen at 4K-UHD
Fast transit pixels for smooth greyscale and improved contrast.
Display capability up to 4K-UHD (3840x2160) |
| Aspect Ratio: |
16:9 |
| Fill Factor |
N/A as Smooth Picture DMD |
| Key Features: |
Video & Graphics Processing
- DisplayPort 1.2
- 2 x HDMI 2.0b HDCP 2.2
- HDR processing
- 2 x HDMI 1.4b HDCP 1.4 for Dual Pipe processing and Frame Sequential 3D Format.
- Sequential Processing: 3D via single HDMI 1.4b input
- Dual Pipe Processing: 3D Left and Right eyes via two HDMI1.4b inputs.
- Syncronisation of active glasses.
- 3G-SDI with loop-through.
- DICOM simulation mode.
- DMX Art-Net
General Features
- Constant Brightness control
- Multi-Projector Brightness control
- Compatible with selected competitor lenses via lens converter
- Selectable EDID
- Custom Start-up Logo
Geometry Correction
- 4-Cornerstone, Vertical & Horizontal Keystone, Pincushion & Barrel, Arc and Image Rotation
- Non-linear warp
- Digital Zoom, Pan and Scan
- Blanking control for custom input window sizing.
- Scaling available for fixed aspect ratio screens.
- Unscaled processing for pixel mapped display
Edge Blending
- Blending control available for all sides with width control.
- Correction for non-active pixels at the edge of the display.
- Electronic Black Level Compensation.
Picture in Picture
- Two sources can be displayed symultaneously using 2D inputs. either picture in picture (PIP) , or side by side (PBP), with the original aspect ratios maintained.
HDBaseT® Interface
- Built in support for reception of uncompressed High Definition Video over standard CAT5e/6 LAN cable
- Allows projector to be placed up to 100m from source with low cost cabling
- Supports up to 4K UHD 3840 x 2160@60Hz 4:2:0 or 4K UHD 3840 x 2160@30Hz 4:2:2
Colour Processing
- Four colour modes available
- Powerful seven point colour correction for accurate colour matching with presets.
- Easy colour temperature selection
- Manual seven point colour adjustment
- Traditional lifts and gains
Projector Controller Software
- Intuitive user interface for network control
- Simultaneous control of user-defined groups of projectors
- At-a-glance monitoring of projector status
Projector Automation
- Real-time clock provides daily on/off automation
- E-mail alerts for system status
|
| Source Compatibility |
2D Graphics standards up to 4K-UHD 3840x2160 resolution at 60Hz via HDMI 2.0, HDBaseT (4:2:0), DisplayPort inputs
3D Graphics standards up to dual-pipe WUXGA 120Hz via HDMI 1.4b inputs
3G-SDI is SMPTE 292M, SMPTE 259M-C and SMPTE 424M compliant.
WUXGA mode
2D sources up to WUXGA 120Hz and 4K-UHD 60Hz can be displayed scaled to fit WUXGA
3D sources up to WUXGA 120Hz can be displayed scaled to fit WUXGA
4K-UHD mode
2D sources up to 4K-UHD will be displayed scaled to fit 4K-UHD
Auto Mode
Sources greater than WUXGA will be displayed scaled to fit 4K-UHD
Sources up to WUXGA will be displayed scaled to fit WUXGA |
| Inputs/Outputs |
| Video & Computer |
| Type |
Connector |
Qty |
DisplayPort 1.2 (2D)
HDMI 1.4b (3D)
HDMI 2.0b (2D)
3G-SDI in (2D)
3G-SDI out
HDBaseT/LAN (2D) |
DisplayPort
HDMI
HDMI
BNC
BNC
RJ45 |
2
2
2
1
1
1 |
.
| Communication & Control |
| Type |
Connector |
Qty |
3D Sync In
3D Sync out
RS-232 Serial Port IN
Wire Remote IN
Wire Remote OUT
RJ-45 LAN Control
USB-A (5V/2A)
3.5 mm Mini Jack for 12V Trigger |
.
.
RS-232
.
.
RJ-45
USB-A
3.5 mm |
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
|
|
| 3D Formats Supported |
Sequential / 1080p @100Hz
Sequential / 1080p @120Hz
Sequential / WUXGA @100Hz (RB)
Dual-Pipe / 1080p @ 50Hz
Dual-Pipe / 1080p @ 60Hz
Dual-Pipe / WUXGA @ 50Hz (RB)
Dual-Pipe / WUXGA @ 60Hz |
| HDTV Formats Supported |
1080p (24Hz, 25Hz, 30Hz, 50Hz, 60Hz)
1080i (50Hz, 60Hz)
720p (50Hz, 60Hz)
2K (24Hz, 25Hz, 30Hz, 50Hz, 60Hz)
4K-UHD (24Hz, 25Hz, 30Hz, 50Hz, 60Hz) |
| Computer Compatibility |
2D
3840 x 2400 @60Hz
3D
Supported Formats will be displayed upto WUXGA |
| Bandwidth |
498 Mpixels/sec via DisplayPort and HDMI2.0. |
| Remote Control |
Addressable IR remote Control, Wireless and wired. On-Board keypad |
| Automation Control |
TBD |
| Colour Temperature |
TBD |
| Operation |
 |
| illumination Type |
Laser Light Source |
| Typical illumination Life |
20,000 hours |
| Lenses |
| Lens |
Part No. |
Optimised Focus Range* |
Lens Shift (Frame) |
| 0.37:1 (Right Angled) |
120-510 |
1.6m - 4.9m |
Vert: 0.65 (U) 0.65 (D) frame, Hor: 0.31 (L) 0.31 (R) frame |
| 0.65-0.85:1 (Right Angled) |
120-511 |
2.8m - 8.4m |
Vert: 0.62 (U) 0.62 (D) frame, Hor: 0.25 (L) 0.25 (R) frame |
| 0.8-1.16:1 (Includes support bracket) |
120-827 |
1.7m - 11m |
Vert: 0.51 (U) 0.51 (D) frame, Hor: 0.20 (L) 0.20 (R) frame |
| 1.16 - 1.49:1 zoom HB |
109-236 |
3m - 15m |
Vert: 0.50 (U) 0.408 (D) frame, Hor: 0.2 (L) 0.2 (R) frame |
| 1.39 - 1.87:1 zoom HB |
105-610 |
4m - 24m |
Vert: 0.65 (U) 0.65 (D) frame, Hor: 0.28 (L) 0.28 (R) frame |
| 1.87 - 2.56:1 zoom HB |
105-611 |
4m - 24m |
Vert: 0.65 (U) 0.65 (D) frame, Hor: 0.28 (L) 0.28 (R) frame |
| 2.56 - 4.16:1 zoom HB |
105-612 |
9.1m - 45m |
Vert: 0.65 (U) 0.65 (D) frame, Hor: 0.28 (L) 0.28 (R) frame |
| 4.16 - 6.96:1 zoom HB |
105-613 |
12m - 80m |
Vert: 0.65 (U) 0.65 (D) frame, Hor: 0.28 (L) 0.28 (R) frame |
| 6.92 - 10.36:1 zoom HB |
109-235 |
12m - 80m |
Vert: 0.65 (U) 0.45 (D) frame, Hor: 0.28 (L) 0.28 (R) frame |
* Lens focal ranges above are the optimised distances but are likely to focus further, please contact your RSM for more details. Lens ratio tolerances: E-Vision Series: +/-3%. HighLite Series: +/- 5%. M-Vision Series: +/- 2%. Titan Series: +/-2%, INSIGHT Series: +/-2%,
|
| Lens Mount |
Motorised Shift, Zoom and Focus.
Intelligent Lens Memory with 10 user-definable pre-set positions for zoom lenses. |
| Mechanical Mounting |
Front/Rear Table
Front/Rear Ceiling
Adjustable Front/Rear Feet |
| Orientation |
Table Top or Inverted: Yes
Pointing Up: Yes
Pointing Down: Yes
Roll (Portrait): Yes |
| Power Requirements |
200VAC to 230VAC selectable, 50/60Hz single phase |
| Power Consumption |
200V Typical: < 2250W, Maximum < 2400W |
| Thermal Dissipation |
TBD |
| Fan Noise |
Max. Typical 51 dB +2dB deviation
Eco Typical 48 dB +2dB deviation |
| Operating/Storage Temperature: |
TBD |
| Operating Humidity |
TBD |
| Weight |
54.5 kg / 120.1 lbs |
| Dimensions |
L: 760 mm, W: 525 mm, H: 318 mm (Excl. handles)
L: 29.9 in, W: 20.6 in, H: 12.5 in (Excl. handles) |
| Safety & EMC Regulations |
cTUVs, CB, FCC Class A, CE, CCC, KC, FDA, BSMI |
| Accessories |
| Accessory |
Part No. |
Remote Control (with Battery)
HDMI Cable (1x 2m)
Lens Cap/Hole Cap (Without Lens)
AC Power Cord (US Type x 1, EU Type x 1, UK Type x 1, China Type x 1)
Important Information Booklet |
|
*Dimensions included for reference only and are subject to change. Please download the full set of CAD files for this display for more accurate information.
|
