INSIGHT 4K HFR 360 (Preliminary)
27,000 Lumens | Contrast Ratio: 2,000:1 | Part Number: 119-667
|
Key Specifications:
|
Colour System: |
3-chip DLP® |
Display Type: |
3 x 1.38" DarkChip™ DMD™
|
DMD Specification: |
4096 x 2160 pixels native, +/- 12° tilt angle
Fast transit pixels for smooth greyscale and improved contrast. |
Aspect Ratio: |
1.90:1 |
Fill Factor |
87% |
Key Features: |
- Up to 360 FPS Display capability at native 4096 x 2160 resolution.
- Accepts up to 6 inputs in parallel and displays them sequentially with smooth greyscaleand amazing colour.
- High Brightness laser illuminated.
- Compact integrated chassis.
- Long life light source.
- Sealed optics.
- Maintenance free.
- 3D capable.
- DisplayPort 1.2 and HDMI 2.0 inputs.
Video & Graphics processing
- Up to 6 x 60 fps 4096 x 2160 pixels sequential input via single DisplayPort input.
- Dark Time insertion matched to fast switching glasses.
- Smear reduction for 2D displays.
- Synchronisation of active glasses (or polarising switcher, TBC).
- Image blanking (linear curtains) on all edges.
- Low latency processing.
Color adjustments
- Up to 12 bits color processing (depending on source and input type).
- Degamma table maps input to 16 bit palette (R, G & B) for display.
- Degamma selection from a list of parametric curves.
- Individual R, G & B lift and gain.
- Black and White level adjustment via Brightness & Contrast control.
ColorMax™
- Accurate matching of projectors in tiled or blended applications.
- User selection and storage of primary and secondary user defined color targets up to 7 points.
Projector Control
- Keypad with on-screen display.
- Remote control - IR or cable.
- Network control via RJ45.
- Served web page for remote control via tablets and smart phones. Wireless requires access point (not supplied).
- PC control application.
Mounting
- Built-in stacking points.
- Eyebolts for quick mounting.
- Optional mounting/grab rail.
Lens features
- Robust lens mount with memorised position, zoom and focus.
- Extensive lens shift encompassing all lens capabilities.
- High quality sharp lenses designed for 4K performance with long focal distances.
|
Source Compatibility |
Graphics standards up to 4096 x 2160 at 60 fps via DisplayPort. 60 fps via HDMI. Higher input frame rates supported at lower input resolution. |
Inputs/Outputs |
Video & Computer |
Type |
Connector |
Qty |
DisplayPort 1.2
HDMI 2.0 |
DisplayPort
HDMI |
6
6 |
.
Communication & Control |
Type |
Connector |
Qty |
3D Sync Out
3D Sync In
LAN
RS232
Wired Remote In
Service Port |
BNC
BNC
RJ45
9-pin D Sub
3.5mm Stereo Jack
USB Type A |
1
1
1
1
1
1 |
|
3D Formats Supported |
Dual Pipe
Frame Sequential
|
HDTV Formats Supported |
4096 x 2160p (24, 25, 29.97, 30, 50, 59.94, 60 Hz) 3840 x 2160p (24, 25, 29.97, 30, 50, 59.94, 60 Hz) 1080p (24, 25, 29.97, 30, 50, 59.94, 60 Hz)
|
Computer Compatibility |
Up to 4096 x 2160 |
Bandwidth |
N/A |
Remote Control |
Wired remote control
On-Board keypad with OSD |
Automation Control |
RS232
LAN |
Colour Temperature |
User selectable from 3300 to 10000K |
Operation |
|
illumination Type |
Laser Light Source |
Typical illumination Life |
20,000 hours |
Lenses |
Lens |
Part No. |
Optimised Focus Range* |
Lens Shift (Frame) |
At Native 4K |
- |
- |
- |
0.93:1 fixed |
117-310 |
0.5m - 100m |
Vert: 0.21 (U) 0.21 (D) frame, Hor: 0.08 (L) 0.08 (R) |
1.13 - 1.72:1 |
115-627 |
2.5m - 100m |
Vert: 0.34 (U) 0.19 (D) frame, Hor: 0.08 (L) 0.10 (R) frame |
1.65 - 2.60:1 |
115-630 |
3.5m - 100m |
Vert: 0.40 (U) 0.20 (D) frame, Hor: 0.13 (L) 0.13 (R) frame |
2.53 - 4.98:1 |
115-632 |
4.5m - 100m |
Vert: 0.37 (U) 0.20 (D) frame, Hor: 0.13 (L) 0.13 (R) frame |
At UHD |
- |
- |
- |
0.99:1 fixed |
117-310 |
0.5m - 100m |
Vert: 0.27 (U) 0.20 (D) frame, Hor: 0.10 (L) 0.11 (R) |
1.21 - 1.83:1 |
115-627 |
2.5m - 100m |
Vert: 0.40 (U) 0.20 (D) frame, Hor: 0.10 (L) 0.14 (R) frame |
1.76 - 2.77:1 |
115-630 |
3.5m - 100m |
Vert: 0.45 (U) 0.20 (D) frame, Hor: 0.10 (L) 0.17 (R) frame |
2.70 - 5.31:1 |
115-632 |
4.5m - 100m |
Vert: 0.42 (U) 0.20 (D) frame, Hor: 0.10 (L) 0.17 (R) frame |
* Lens focal ranges above are the optimised distances but are likely to focus further, please contact your RSM for more details. Lens ratio tolerances: E-Vision Series: +/-3%. HighLite Series: +/- 5%. M-Vision Series: +/- 2%. Titan Series: +/-2%, INSIGHT Series: +/-2%,
|
Lens Mount |
Motorised shift, zoom and focus.
Intelligent Lens Memory with user-definable preset positions. |
Mechanical Mounting |
Front/Rear Table
Front/Rear Ceiling
Adjustable Front/Rear Feet |
Orientation |
Table Top or Inverted: Yes
Pointing Up: Yes
Pointing Down: Yes
Roll (Portrait): Yes |
Power Requirements |
200 - 240VAC 50/60Hz single phase |
Power Consumption |
3400 |
Thermal Dissipation |
11600 |
Fan Noise |
54 dBA |
Operating/Storage Temperature: |
Operating: 0 to 40C (32 to 104F)
Storage: -10 to 50C (14 to 122F) |
Operating Humidity |
20 to 80% non-condensing |
Weight |
100 kg / 220 lbs |
Dimensions |
H: 47.9 cm W: 72.2 cm L: 100.3 cm
H: 18.9 in W: 28.4 in L: 39.5 in |
Safety & EMC Regulations |
CE, FCC Class A, UL, CCC |
Accessories |
Accessory |
Part No. |
Mounting rail
Replacement filter set
Lens Adapter Kit for 0.72:1 4K Schneider Lens |
118-471 118-534 117-343 |
*Dimensions included for reference only and are subject to change. Please download the full set of CAD files for this display for more accurate information.
|
