Radiance LED VX-C Series 1.2 FSA Panel

Part Number: 709-212

Product Overview:

Engineered with a lower cost-to-performance ratio in mind, the VX Series from Radiance LED creates impressive solutions for spaces that need an exceptional, but cost-effective display. With a lower brightness range, this series is a perfect fit for environments with lower ambient light exposure. The VX Series also features Radiance LED's new, optional CrystalView protective technology on every pixel pitch model, adding even more value to an already impressive set of features.

Creating bright and vivid imagery in a wide variety of venues, the Radiance LED VX Series delivers stunning color saturation & contrast. Built on a native 16:9 aspect ratio, the individual VX Series LED panels provide seamless building blocks for creating custom resolutions in various shapes & sizes. This series features a thin installation profile, wide viewing angles and silent operation due to its fan-less panel design providing a dynamic display solution for a wide variety of environments.

Technical Specifications:

Part Number 709-212
Pixel-Pitch (mm) 1.2
Cabinet Resolution (pixel) 480 / 270
LED Type Black SMD
Pixel Configuration SMD 3-In-1
Pixel Density (pixel/m2) 629882
Modules per Cabinet 4
Brightness (Max) 600
Brightness (Calibrated) 600
Color Temp (Default) 3000 -10000
Gamma (Default) User Adjustable
Dimming Capability 0-255 Levels
Refresh Rate 3000Hz
Gray Scale 16-bit
Color Depth 281 Trillion Colors
Viewing Angle (Horizontal) 160
Viewing Angle (Vertical) 140
CrystalView Option Yes
LED Lifetime <100,000 Hours
Power Input 100-240 VAC; 50-60Hz
Power Consumption (Max) (watts/cabinet) 130
Power Consumption (Avg) (watts/cabinet) 43
Cabinet Size (mm) 604.8 x 340.2 x 72.5
Cabinet Weight (Lbs) 15.300
Temperature (Operation) -10 - 40° C
Temperature (Storage) -20 - 60° C
Relative Humidity (Operation) 10 - 80% RH
Relative Humidity (Storage) 10 - 85% RH
Service Access Front
IP Rating
Certifications cTUVus, CB, CE, FCC
