Specification Sheet
Radiance LED RCS-G 2.9 Medium
Part Number: 720-291
Product Overview
For applications needing high-performance displays with rapidly changing layouts, the RCS Series from Radiance LED is the perfect solution. Engineered for maximum flexibility, this series is easily set up, and torn down with Digital Projection's RapidRig Technology. With no required backing frame, the RCS Series panels can be seamlessly configured into free standing displays or flown from above from headers and/or trusses.
Featuring an easy-to-manage square panel design, as well as front and rear service options, the Radiance LED RCS Series is an incredible solution for Digital Signage, Houses of Worship and Performance Centers that need to redesign their display elements for each show or event.
Technical Specifications
| Specification | |
| Part Number | 720-291 |
| Pixel-Pitch (mm) | 2.9 |
| Cabinet Resolution (pixel) | 168 / 252 |
| LED Type | Black SMD |
| Pixel Configuration | SMD 3-In-1 |
| Pixel Density (pixel/m2) | 112896 |
| Modules per Cabinet | 6 |
| Brightness (Max) | 1000 |
| Brightness (Calibrated) | 1000 Nits |
| Color Temp (Default) | 3000 - 10000 |
| Gamma (Default) | User adjustable |
| Dimming Capability | 0-255 Levels |
| Refresh Rate | 3840Hz |
| Gray Scale | |
| Color Depth | |
| Viewing Angle (Horizontal) | 160 |
| Viewing Angle (Vertical) | 140 |
| CrystalView Option | No |
| LED Lifetime | 50,000 Hours |
| Power Input | 100-240 VAC; 50-60Hz |
| Power Consumption (Max) (watts/cabinet) | 400 |
| Power Consumption (Avg) (watts/cabinet) | 132 |
| Cabinet Size (mm) | 500 x 750 x 68 |
| Cabinet Weight (Lbs) | 22.040 |
| Temperature (Operation) | -20 - 40° C |
| Temperature (Storage) | -30 - 60° C |
| Relative Humidity (Operation) | 10 - 90% RH |
| Relative Humidity (Storage) | 10 - 80% RH |
| Service Access | Front / Rear |
| IP Rating | IP30 |
| Certifications |
| Radiance LED System Components and Accessories | |
|
|
Specifications subject to change without notice. ©2020 Digital Projection.
 |
