Radiance LED RCS-G 3.9 Medium

Part Number: 720-391

Product Overview:

For applications needing high-performance displays with rapidly changing layouts, the RCS Series from Radiance LED is the perfect solution. Engineered for maximum flexibility, this series is easily set up, and torn down with Digital Projection's RapidRig Technology. With no required backing frame, the RCS Series panels can be seamlessly configured into free standing displays or flown from above from headers and/or trusses.

Featuring an easy-to-manage square panel design, as well as front and rear service options, the Radiance LED RCS Series is an incredible solution for Digital Signage, Houses of Worship and Performance Centers that need to redesign their display elements for each show or event.

Technical Specifications:

Part Number 720-391
Pixel-Pitch (mm) 3.9
Cabinet Resolution (pixel) 128 / 192
Pixel Configuration SMD 3-In-1
Pixel Density (pixel/m2) 65536
Modules per Cabinet 6
Brightness (Max) 1000
Brightness (Calibrated) 1000 Nits
Color Temp (Default) 3000 - 10000
Gamma (Default) User adjustable
Dimming Capability 0-255 Levels
Refresh Rate 3840Hz
Gray Scale
Color Depth
Viewing Angle (Horizontal) 160
Viewing Angle (Vertical) 140
CrystalView Option No
LED Lifetime 100,000 Hours
Power Input 100-240 VAC; 50-60Hz
Power Consumption (Max) (watts/cabinet) 350
Power Consumption (Avg) (watts/cabinet) 350
Cabinet Size (mm) 500 x 750 x 68
Cabinet Weight (Lbs) 22.040
Temperature (Operation) -20 - 40° C
Temperature (Storage) -30 - 60° C
Relative Humidity (Operation) 10 - 90% RH
Relative Humidity (Storage) 10 - 80% RH
Service Access Front / Rear
IP Rating IP30
