Specification Sheet


Radiance LED Outdoor Series 6.0 RSA Panel

Part Number: 700-960



Product Overview

Creating outdoor displays that captivate and draw attention is easy to do with the Outdoor Series by Radiance LED. Offering up to an astounding 6,000 nits of brightness, this series is perfect for stadiums, amusement parks, digital signage, and residences that must content with direct sunlight and still showcase stunning color saturation & contrast.

Engineered for a wide variety of open-air environments, the individual Outdoor Series LED panels have been ruggedized with sealed optics to be weather resistant, waterproof, UV resistant and corrosion resistant for long-lasting performance.

Technical Specifications

Specification
Part Number 700-960
Pixel-Pitch (mm) 6.0
Cabinet Resolution (pixel) 160 / 160
LED Type Black SMD
Pixel Configuration SMD 3-In-1
Pixel Density (pixel/m2) 27777
Modules per Cabinet 8
Brightness (Max) 6000
Brightness (Calibrated) 5500
Color Temp (Default) 4000-9500
Gamma (Default) User Adjustable
Dimming Capability 0-255 Levels
Refresh Rate 2160Hz
Gray Scale 14-bit
Color Depth 4.4 Trillion Colors
Viewing Angle (Horizontal) 140
Viewing Angle (Vertical) 90
CrystalView Option No
LED Lifetime <100,000 Hours
Power Input 100-240 VAC; 50-60Hz
Power Consumption (Max) (watts/cabinet) 680
Power Consumption (Avg) (watts/cabinet) 227
Cabinet Size (mm) 960 x 960 x 140
Cabinet Weight (Lbs) 95.900
Temperature (Operation) -20 - 50° C
Temperature (Storage) -30 - 60° C
Relative Humidity (Operation) 10 - 90% RH
Relative Humidity (Storage) 10 - 90% RH
Service Access Rear
IP Rating IP65 / 54
Certifications UL, CB, CE, FCC, CCC

Radiance LED System Components and Accessories

  • HD & UHD 4K LED Controllers
  • Standard and/or Custom Mounting Solutions
  • Long-term Spares Package for Service and Maintenance
  • Trim Cladding for LED Mounting Frame
  • Engineering Design Support
  • Concierge Project Management Services
  • Installation Support Services





Specifications subject to change without notice. ©2020 Digital Projection.
