Radiance LED Performance Series 3.0 FSA Panel

Part Number: 700-300

Product Overview:

Engineered to create the very best in LED video wall viewing experiences, the Radiance LED Performance Series by Digital Projection delivers stunning imaging in nearly any indoor ambient light condition. With exceptional color saturation & contrast, this series is perfect for creating that "Wow" effect in displays that engage and inspire.


Countless integration options of the Radiance LED Performance Series include flush-mounted installations, ADA compliant wall mounting (3.75" depth), floor supported arrays, and ceiling suspended capabilities, just to name a few. Adding stereoscopic 3D and Redundancy options to that list of features makes the Radiance LED Performance Series an extraordinary video wall solution for spaces that will captivate the viewer.


Technical Specifications:

Part Number 700-300
Pixel-Pitch (mm) 3
Cabinet Resolution (pixel) 192 / 216
LED Type Black SMD
Pixel Configuration SMD 3-In-1
Pixel Density (pixel/m2) 111111
Modules per Cabinet 6
Brightness (Max) 1500
Brightness (Calibrated) 1000
Color Temp (Default) 6500K
Gamma (Default) User Adjustable
Dimming Capability 0-255 Levels
Refresh Rate >3900Hz
Gray Scale 14-bit
Color Depth 4.4 Trillion Colors
Viewing Angle (Horizontal) 160
Viewing Angle (Vertical) 140
CrystalView Option No
LED Lifetime <100,000 Hours
Power Input 100-240 VAC; 50-60Hz
Power Consumption (Max) (watts/cabinet) 220
Power Consumption (Avg) (watts/cabinet) 73
Cabinet Size (mm) 576 x 648 x 83
Cabinet Weight (Lbs) 26.450
Temperature (Operation) -10 - 40° C
Temperature (Storage) -20 - 60° C
Relative Humidity (Operation) 10 - 90% RH
Relative Humidity (Storage) 10 - 90% RH
Service Access Front
IP Rating F: IP30 / R: IP20
Certifications UL, CB, CE, FCC, CCC
