M-Vision Laser 21000 WUXGA
M-Vision Laser 21000 WUXGA
M-Vision Laser 21000 WUXGA

M-Vision Laser 21000

Solid State Laser Phosphor

・1 チップDLP® 0.96″ DarkChip™ DMD™
・21000 ANSI Lumens
・WUXGA 解像度
・Colorboost® テクノロジー
・IP規格 IP60光学系統

詳細を見る :

仕様 PDF

The M-Vision Laser 21000 is the first of a new breed of Single Chip DLP Laser projectors from Digital Projection. This lamp-free, laser-phosphor projector utilises new Colorboost+Red Laser technology to bring you the most realistic and saturated colours at previously unimaginable luminance levels. Such power and accuracy, combined with all-new intelligent processing brings the overall performance ever closer to that of a 3-Chip DLP projector – at a much more affordable price.

Boasting an unprecedented 21,000 lumens output and a 10,000:1 contrast ratio, the new M-Vision Laser 21000 brings budget-sensitive applications a large-screen imaging solution and near 3-Chip performance at a 1-Chip price point.

The optical system, from the laser light source up to the lens is completely sealed and can be considered IP60 rated. This ensures that light output and colour performance will not be degraded due to the ingress of dust. Additionally, this projector is completely filterless as the system is liquid cooled and uses a radiator heat exchanger, minimising maintenance as no replacement or cleaning of filters is necessary and allows unrestricted airflow.

Venues contending with ambient light, as well as applications needing a powerful yet budget-conscious large-format imagery solution without sacrificing on colour accuracy will directly benefit from the M-Vision 21000 class leading light output, contrast ratio and colourimetry. Perfectly suited to all applications where high brightness is required, no feature has been overlooked. DisplayPort accepts frame rates up to 60 Hz and HDMI 1.4b for Side by Side, Frame Packing & Top Bottom 3D formats. Motorised shift, zoom and focus across the whole lens range offers superb flexibility and ease of setup. This projector is not a class leader – it is in a class of it’s own.

Key Features

  • 21,000 ISO / 18,600 ANSI Lumens
  • WUXGA Resolution
  • 10,000:1 Dynamic Contrast
  • Color Boost + Red Laser
  • Sealed Optics
  • Part Number: 119-673

Spec Sheet

Download download View PDF view

Downloads

M-Vision 21000 WU, Part Number: 119-673
Download download View PDF download
M-Vision Laser 21000 WUXGA
  • 21,000 Lumens
  • 20,000 Hours Illumination
  • 0.96″ DarkChip™ DMD™
  • MultiAxis Orientation

Core Technologies

Request More Info

If you need more information or a call back from our team, please fill in the form below and your local business development manager will get back to you

Send us a message

By submitting this form you agree to Digital Projection storing your data for the purposes of responding to your enquiry.

Smart Stack System

SmartStack System

  • The intuitive stacking mechanisms means that M-Vision 23000 projectors can be lock-stacked without any additional rigging frames or expense.

Projector Control Software

Projector Controller

  • Ideal for use in large installations or where projectors are in multiple locations in a building, the software can dramatically reduce the time required for set up and configuration – all from a single network enabled PC.

MultiAxis Projector Orientation

MultiAxis Orientation

  • For maximum flexibility, the M-Vision 21000 can be operated in both Portrait and Landscape mode, pointing up and down and every angle in between
